Uses and Features
The CVF filter is an automatic round dust filter designed for operation in deep vacuum conditions up to 600 millibar. The filter serves as the primary filter in central dust extraction systems House-Vacuum and for dust filtration in pneumatic conveying facilities with high dust loads. It is designed for intensive and continuous operation in the metal, mineral raw materials, chemical, pharmaceutical, wood processing, and mixing plant industries.
All filter components are laser-cut, the filter body is fully welded, and constructed from steel sheets / stainless steel with thicknesses of 3–5 mm, providing mechanical strength, EXTRA HEAVY DUTY construction, and long-term process durability.
Methods for cleaning filter elements
The ROTARY-JET (rotary lance) method is the most efficient cleaning system in the world. The rotary lance provides perfect air distribution along the entire filter, with uniform cleaning pressure that allows each pleat in the filter to be cleaned individually and thoroughly. Using the rotary lance significantly extends filter life, greatly reduces noise levels, and enables substantial savings (up to 70%) in compressed air consumption compared to other cleaning methods.
- The PULSE-JET method with a GO-CO nozzle ensures efficient and uniform cleaning along the entire length of the filter during operation. This method prevents areas of the filter from remaining uncleaned, which can occur with conventional PULSE-JET cleaning.
Technical Specification
- Models: CVF-1, CVF-2, CVF-3, CVF-4, CVF-5, CVF-6.
- Filter types: Cartridge or bag with cages.
- Filter media: Reinforced polyester, PTFE membrane, anti-static.
- Flow rates: 500-4,500 m³/h.
- Construction materials: Steel, galvanized steel, 304 stainless steel, and 316 stainless steel.
- Coating system: Electrostatic epoxy C3-C5 according to customer requirements.
