Uses and Features
Oil-free blower/vacuum pump suitable for medium pressures up to 500 millibar, vacuum up to 400 millibar, and a flow rate of up to 3,000 m³/h. The blowers are used for pneumatic conveying, creating a vacuum in machines and production processes, for central vacuum systems, and for ventilation in coating lines, fish farms, and textile factories.
Technical Specification
- Drive : Direct, belt, and direct with clutch.
- Construction Material : Aluminum die-cast body.
- Electrical Power : 0.5 - 40 HP.
- Vacuum : 10-400 [mbar].
- Pressure : 10-500 [mbar].
- Capacity : 50-3,000 [m³/h].
- Motors : High-efficiency motors suitable for VFD operation, option for explosion-proof motors ZONE1 and ZONE2.
- Additional Accessories : Silencer, vibration mounts, flexible couplings, inlet filter, pressure/vacuum relief valve, non-return valve, vacuum/pressure gauge, and control panel.
Advantages for users of ventilation fans and engineering
- HEAVY DUTY industrial structure.
- Option for belt drive.
- Option for explosion protection.
- Aluminum cast structure with spark protection.
- Fan adapted to the customer's specific process.
- Attractive price.
