Uses and Features
The VERTI FLOW filter is an automatic dust filter used to filter air emitted from production processes that release dust and particles at low concentrations.
The filter is designed for intensive and continuous operation in the metal, mineral raw materials, chemical, pharmaceutical, wood processing, and mixing plant industries.
All filter components are laser-cut, the filter body is fully welded, and constructed from steel sheets / stainless steel 316 / stainless steel 304 with thicknesses of 3–5 mm, providing mechanical strength, EXTRA HEAVY DUTY construction, and long-term process durability.
Filter element cleaning method
- The PULSE-JET method with an enhanced cleaning nozzle provides efficient cleaning along the entire length of the filter during operation. This method reduces areas of the filter that remain uncleaned, which can occur with conventional PULSE-JET cleaning.
Technical Specification
- Models: VF-2 - VF-64.
- Construction materials: Steel, galvanized steel, stainless steel 304/316.
- Filter types: Cartridge.
- Filter media: Reinforced polyester, anti-static, polyester with PTFE membrane.
- Flow rates: 500-32,000 m³/h.
Advantages for users of ventilation fans and engineering
- High filtration efficiency.
- Reliable and safe continuous operation.
- EXTRA HEAVY DUTY industrial construction.
- Design allows for easy and convenient operation and maintenance.
- Significant cost savings on spare parts.
- Filter elements with German technology, washable with water.
